90 Degrees Right Outlet DC Vehicle Inlet Socket
| Certification |
GB/T20234.3-2015 |
| Rated Voltage | 750V AC |
| Rated Current | 200A |
| Withstand Voltage | 3500V AC |
| Insulation Resistance | ≥500MQ |
| Operating Temperature |
-30℃〜+50℃ |
|
Protection Degree |
(Mated)IP55(Inside the Charging Connector)IP67 |
|
Flame Retardant Grade |
UL94V-0 |
|
Mating Force |
80N<F<140N |
|
Mating Cycles |
10000(No-load) |
Share:
Related Products
Description
Datasheet
Highlights
| Production Process | ||||
|
Injection Molding Workshop |
Compounding & Mixing Workshop |
Machining Workshop |
Cable Stranding & Cabling |
Heat-Shrink Tubing Production Line |
|
Molding & Tooling Workshop |
Rubber Injection Workshop |
Stamping & Press Workshop |
Irradiation Crosslinking Center |
Embossed Tubing Production Line |
|
① Perfect quality management and process production. |
 |
|
|
② A professional team engaged in the production and research and development of this product for more than 12 years. |
|
③ A first-class and complete production workshop and equipment. |
 |
|
|
④ Comprehensive product testing equipment. We have the first authorized UL sighting laboratory in China. |
